TX7028 Vertical Metal Planer Slotting Machines for Price

PRODUCT HIGHLIGHTS
Wear Resistant and Durable: High-strength alloy steel cutting heads ensure long-lasting performance and cost-effective cutting.
Efficient Cutting: Fast and automatic groove cutting, reducing labor and time costs compared to traditional methods.
Multiple Stroke Speeds: 6 steps of spindle speed options allow for precise control during operation.
Compact Design: Small size makes it easy to operate and move by one person.
Strong Adaptability: Suitable for various slotting angles and material types.

Availability:

Quantity:



Inquire Add to Basket

Model:
TX7028

Product Description

Main technical parameters
Insertion cutting length	mm	65-165 mm (stepless)
Repetition frequency		80-125 per minute
Rotation angle of the cutting head		±90°
Distance between the cutting head and the column guide rail	mm	360mm
Maximum diameter of drilling hole	mm	50
Maximum width of end milling	mm	100
Maximum diameter of vertical milling	mm	25
Maximum tapping diameter		M16
Distance from spindle end face to worktable	mm	80-460
Main spindle speed range	r.p.m	(V) 115-1750 (H) 40-1300
Spindle travel	mm	one hundred and twenty
Workbench size	mm	1200×280
Workbench itinerary	mm	700×300
External dimensions	mm	1352×1600×2130
Motor power	kw	(H )2.2 (V) 2.2
Machine weight	kg	1300/1450

Metal Vertical Slotting Machine for Keyway Processing High Precision Mechanical Slotting Machine Industrial Heavy Duty Slotting Machine Automatic Metal Slotting Machine for Workshop Vertical Slotting Machine
