Specification

B5016C

Max.Slotting Length(mm)

160

No of Ram Strokes Per Minute

23, 32, 44, 48, 67, 92

Swing Angle of Ram(°)

±45

Table Diameter(deg)

305(12”)

Vertical Adjustment of Ram(mm)

160

Distance Between Tool Holding Surface and Column Front(mm)

330

Distance Between Table Surface and Lower End of Ram Slide(mm)

440

Max. Longitudinal Travel of Table(mm)

115

Max. Cross Travel of Table(mm)

320

Max. Rotary Angle of Table(deg)

360

Tool Shank Size(WXH)(mm)

20*25

Max Cutting Force(N)

4500

Max.Table Load-carrying Capacity(KGS)

300

Width of Table Center T-slot(mm)

18

Power of Main Drive Motot(KW)

15/0.85

Rotating Speed of Main Drive Motor(rpm)

700/1410

Net Weight (approx)(KGS)

1000

Overall Dimension(LXWXH)(mm)

1270*1100*1700
